The Maverick5 winch is a mini-monster of UTV recovery power packed into a sleek, compact design. Featuring an all-metal, 3-stage planetary gear system, a submersible, 250-amp solenoid, and 5,000 pounds of pulling capacity, at only 24 pounds there is nowhere this winch can’t go.
Fully-sealed, submersible, water, mud, and snow proof, the Maverick5 includes a 1/4” x 50’ Steel Cable, a galvanized roller fairlead, a hook, tie bars, a corrosive-resistant black body with black zinc clutch handles, and a handheld remote control for versatility and convenience.
Main Features:
• 3.8 HP Permanent Magnet Motor
• All Metal Planetary Gearing
• Submersible, 250 Amp Solenoid
• Automatic Load Holding Brake
• Center Focused Drum
• Fast Line Speeds
• 50′ of Steel Cable
• Roller Fairlead
• Waterproof
• Handheld Remote Control
| Rated Line Pull | 5000 lbs. |
| Gear Train | 3 Stage Planetary |
| Gear Ratio | 165:1 |
| Motor | 12 Volt DC, input power 3.8hp (2.8 kw) |
| Remote Control | Power-In, Power-Out Remote |
| Steel Cable | 1/4” X 50’ |
| Drum Size | 2.01″ X 5.4″ (51.1 mm X 137.16 mm) |
| Net Weight (Cable) | 24 lbs (10.8 kg) |
| Bolt Pattern | 4 Bolt pattern, 3″ X 6.61″ (79 mm X 168 mm) |
| Dimensions (LxWxH) | 15.62″ X 4.61″ X 4.72″ (397MM X 117 mm X 120 mm) |
